Mica Tape Paper Tape Adhesive Tape Slitter and Rewinding Machine

ApplicationMulti Spindle Bobbin Winder: Manily used shielding belt, aluminium foil belt, copper foil belt, PTFE, Ribbon, insulation tape, paper tape, polyimide film and other formed tapes. Our AdvantagesAdvantages:1.This winding machine is controlled by computer2.can be wrapped in different width and height3.Witdth 2-20mm belt can be wrapped at the winder. 4.Excellent package quality5.Highest flexiblility and wide range of applications  Product ParametersTechnical Parameters: Winding Way: ParallelDrive mode: servo motorFrame structure: 3-9 head/ set ( as customer request )Winding speed: 0-300m/MinWidth of tape: 5-20mmWinding Proportion: Computer controlTraverse length: 500 ( as custome request )Winding diameter: 500 mm ( as customer request )Bobbin size: 20-200 mm ( as customer request )  Cutting technical parametersWinding technical parametersMin slitting width2.0mmWinding width2-20mmDischarging inner diameter76mmWinding inner diameter76/152mmUnwinding width800mmWinding stroke0-500mmOuter diameter800mmWinding outer diameterMax 500mmMechanical cutting speed10-200M/MinWinding speed10-200M/MinTensionAutomatic tension control systemTensionConstant tension winding  Drive methodDouble servo motor  Control SystemPLC, touch screen  Production WorkflowCompany ProfileSpoolsCertifications   /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
