2mA/2mA Current Transformer for UPS

ZMPT107-1 Current-type Voltage transformerSmall size,high accuracy,good consistency,for voltage and power measurement  Structural parameters:                                                                                    Front view                             Bottom view  The main technical parameters:  Model ZMPT107-1Rated input current2mARated output current2mATurns ratio1000:1000Phase angle error≤45'(input 2mA,sampling resistor 50Ω)Linear range0~1000V       0~10mA(sampling resistor 50Ω)Linearity≤ 0.2%(20% dot~120%dot)Permissible error-0.6% ≤ f ≤0%(input 2mA,sampling resistor 50Ω)Isolation voltage3000V(AC)Applicationvoltage and power measurementEncapsulationEpoxyInstallationPCB mounting(Pin Length>3mm)Operating temperature-40ºC~+85ºC(PBT shell)Shell MaterialPBT (Note: PBT shell is available for wave soldering)     Direction for use:                                                        Figure I                                                  Figure II1. The typical usage of the product is for the active output (Figure I). R'is a limiting resistor,R is a sampling resistor.2. The product can be directly through the resistance sampling , easy to use ( Figure II).     /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
