High Precision Automatic AC Voltage Stabilizer

SVC Single-Phase High Accuracy Full Automatic AC Voltage StabilizersProduct IntroductionSVC single-phase high accuracy full automatic AC voltage stabilizers is made of regulator, servo motor, automatic control circuit and so in. When the voltage of the network is not steady or the load varies, the automatic sampling control circuit makes a signal to drive the servomotor to adjust the position of the carbon brush of the regulator so as to have the output voltage regulated to the rating and to obtain the steady state.This machine has advantages of small volume, light weight, undistorted waveform, high efficiency, reliable performance, and time-delay, over-voltage, the series of stabilizers driven, of general type, the indeed voltage stabilized sources which can be widely applied to any occasions requiring power to assure the normal operation of your power driven equipmentApplicationIt can be used in computers, test equipment, lighting systems, safety alarm systems-ray systems, communication systems, medical equipment, duplicators, stereo sound equipment, color film developing equipmentTechnical ParameterInput Voltage160~250V Output Voltage0.5KVA-3KVA   220V and 110V5KVA-30KVA     220VRegulation Accuracy220V±3%  110V±3% Frequency 50Hz/60Hz Adjust Time95%Relative Humidity≤95%Ambient Temperature-5ºC ~+ 40ºCWaveform DistortionNo Additional Waveform DistortionLoad Power Factor0.8Electric Intensity1500V/minInsulation Resistance≥2MΩSpecification Size WeightSpecificationProduct Dimension CartonsSVC-0.5KVA22×20.5×16.36SVC-1VA26.5×23.7×184SVC-1.5KVA24.3×23.5×204SVC-2KVA32×29.2×21.84SVC-3KVA34.5×29×262SVC-5KVA54×29.5×30.51SVC-8KVA54×29.5×30.51SVC-10KVA34.5×29.5×541SVC-15KVA36×34×661SVC-20KVA49.2×41×871SVC-30KVA49.2×41×871SVC Three Phase High Accuracy Full Automatic AC Voltage StabilizersProduct IntroductionThis series three-phase stabilizer is the combination of high function single-phase stabilizer.The incoming power of the power network is three-phase four wires system, the output power is also three-phase four wires with three electric meters to separately indicate three-phase and shift switch and voltage meter to shifting and surveying each phase.ApplicationIt is widely used in computers, test equipment, lighting systems, safety alarm systems-ray systems, communication systems, medical equipment, duplicators, stereo sound equipment, industrial automatic equipment, color film developing equipment, digital control machine tools, checkout equipment, TV sets, and office appliances.Technical SpecificationInput VoltagePhase voltage 160~250V, line voltage 277V~430V  Output VoltagePhase voltage 220V, line voltage 380VRegulation Accuracy±3% Frequency 50Hz/60Hz Adjust Time95%Relative Humidity≤95%Ambient Temperature-5ºC ~+ 40ºCWaveform DistortionNo Additional Waveform DistortionLoad Power Factor0.8Electric Intensity1500V/minInsulation Resistance≥2MΩSpecification Size WeightSpecificationProduct Dimension CartonsTNS-6KVA 39×31.5×771TNS-9KVA  43.5×36×771TNS-15KVA48×36×701TNS-20KVA51.5×4.05×851TNS-30KVA59×46×1091TNS-40KVA64.5×52.5×1091TNS-50KVA64.5×52.5×1091TNS-60KVA64.5×52.5×1091  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
