High Isolated Unregulated DC to DC Converter Exxxxs/D 1W

High Isolated Unregulated DC to DC Converter  EXXXXS/D-1WFeatures:Low cost, small size.High power density.High galvantic isolation.No heat sink required.Regulated single output.Fixed input, Unregulated Dual Output3KV isolation.Rated 1W, 2W output.Industrial standard pin-out.PCB Mounting.Applications:Electric Power System, Power monitoring, voltage conversion.Dual power isolation in digital communication ports of RS232/485, CAN bus.Power supply isolation in intelligent control, security equipments, telecom, etc.Safety isolation in ground loop elimination, medical equipments and instrument.Isolation & power supply for analogue electric circuit ( Transmitter & sensors).Power supply isolation & transfer for safety monitoring and smart building system.Ground loop interference control.Car electric circuit power isolation & distribution.Battery power supply, voltage transfer, power distribution.PLC, DCS, PC isolation regulated power supply.OUTPUT SPECIFICATIONSItems:Testing conditionMinTypMaxOutput accuracy:At full load and nominal Vin  ± 5%Output power: 0.1W1W1WLine regulation:For Vin change of 1%  1.2Load regulation:From 20% to full load 10%15%Ripple and noise:20MHz bandwidth  150 mV p-pTemperature drift:   ± 0.02%/° CMinimum load   10%Switching frequency  100KHz Over load protection% of FL at nominal input 120 Short circuit protection Momentary    /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
