IntroductionFiber ASE wideband light source module adopts spectral flattening technology, and has high output power. Its working wavelength covers C+L band, which is suitable for fiber sensing applications. RS-232 interface and upper computer software can be provided to facilitate the monitoring of the status of the light source module.FeaturesStable powerFlat spectrumRemote monitoringApplicationsFiber sensingMedical imaging Fiber optic device testing ParametersUnitTyp.NotesCovering the wavelengthnm1030~108050nm@10dBOutput powermW10/20/200Constant powerSpectral flatnessdB10 Isolation degree of outputdB45 Short-time stability(15 min)dB≤ 0.02 Long-term stability(8 h)dB≤ 0.05 Degree of polarizationDOP≤ 0.2 Type of pigtail fiber connector-FC/APC Pigtail type-Hi1060 Operating temperature°C-20 ~ +65 Storage temperature°C-40 ~ +85 Power supply mode-DC 5V OR AC 220V SizemmBenchtop260×285×115Module 90(W)×70(D)×15(H)Communication protocol-RS232Optional power adjustment and PC softwareNote:Output power and flatness can be customized according to customer requirements;The stability test environment is 25ºC after 10 minutes of product preheating.Ordering informationZGWavelength rangeOutput powerDiameter of pigtail casingFiber lengthConnector Packaging Type 1060=1060nm10= 10mW9-0.9mm0=Flange0=NoneB=Benchtop20= 20mW2-2mm1 =1M1=FC/APCM=Module100=100mW200=200mW2 =2M2=FC/PC /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
