FTTH 1310nm Mini Fiber Optical Transmitter Direct Modulation Optical Transmitter with AGC

★Description 1310nm Direct Modulation Optical Transmitter With AGC (DT-DMOT-1310-xx dbm) series directly modulated optical transmitter adopts high-performance DFB laser, operating in 1310nm frequency range, optical transmitter modulates headend RF signal into 1310nm wavelength optical signal, and combines the modulated optical signal to fiber cable, and completes far distance, large area cover transmission for image, audio and data. ★Specification                          Items                                                                                                                            Units                                                                           Parameters                                                                            RemarkOpticalOutput optical powermW4~31 Optical wavelengthnm1310±20 Optical connector-SC/APC or FC/APC Optical return lossdB45 RFFrequency rangeMHz47~862 In-band flatnessdB±0.75 RF input leveldBuV80±5 Level adjustment rangedB±70.2dB stepRF level control mode Automatic/manual C/NdB51 -1dBm receiving optical power, 5km fiberC/CTBdB65C/CSOdB60RF connector Standard F type PhysicalOperation temperatureºC-10~+55 Power voltageVAC110~265 Outer dimensionmm440×370×44 Weightkg4.8     /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
