Compact Miniature DP & USB Signal Slip Rings Capsule Collector

This series slip rings can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary to a rotating structure. It is also called a rotary electrical interface, commutator, collector, swivel or an electrical rotary joint.ACN022-01S is a capsule slip ring with DP connector ,it's used for display port ,same as HD-SDI,USB,HDMI.ACN series have compact inner structure and stable transmission. Ring number are range from 2 rings  up to 100 rings.Power and signal are easily to be integrated into one slip rings under our years of proven technique.Typical outside diameter is 5.5mm,12.4mm,22mm in these series.AdvantagesSmall size Compact designWith DP cableSmooth rotationApplicationsSurveillanceMechanical armDisplay equipmentRadar antennaOptionalCable lengthCurrent & ring numbersSignal typeIP protection grade  Product ParametersACN022-01SSpecificationCircuits & Current1*DP cableVoltage0~400VAC/VDCDielectric strength≥100V@50Hz (signal)Insulation resistance≥10MΩ@100VDC (signal)Operating speed0-100 rpmContact materialPrecious metalHousing materialEngineering plasticsConnectorDP female connectorOut diameter22 mmWorking temperature-20°C ~ +60°C Outline drawing   /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
