Cyb1824 Differential Sensor Pressure Transmitter

SummaryCYB1800 series differential pressure transmitter carefully selects high reliable silicon piezoresistive pressure sensor as the sensitive core according to the application characteristics of different industries, and outputs standard signals applied to industrial application and networking through temperature compensation, digital circuit correction and signal conditioning. The production process continues the rigorous work style and fine process control of the industry. Each type of products has been carefully designed, components screened, process verified and solidified, fatigue stress relief, aging, environmental simulation test and other processes to ensure the stability and reliability of each product.CYB1800 series differential pressure transmitter has universal design suitable for multi industry application, also special design for different industry application characteristics. We will carefully analyze the customer's working environment and requirements, then select the most appropriate products; we can also customize the products according to the user's special requirements, so that every user of Huatian can get the best use experience.  ApplicationFor many years, CYB1800 series differential pressure transmitter has been widely used in all kinds of fluid measurement users, especially in coal mine, oil field, petrochemical, environmental protection, medicine, water and other industries, for its excellent accuracy and reliability.  Technical Index Range0kPa~10kPa…3.5MPaPressure formdifferential pressureOutput signal4~20 mA(Hart protocol could be added)RS4850~10V(range could be customized)Accuracy0.1(customized)0.25(typ.)0.5(max)Long-term stability (%FS/year)±0.1(typ.)±0.2(max)Zero Temperature Drift (%FS/ºC)±0.03(≤100kPa)±0.02(>100kPa)Sensitivity Temperature Drift (%FS/ºC)±0.03(≤100kPa)±0.02(>100kPa)Compensation Temperature (ºC)0~50(≤100kPa)-10~70(>100kPa)Working Voltage (VDC)+12~+30Medium Temperature (ºC)-40~+80Load resistance (Ω)Current type: ≤(U-12)/0.02(Ω)Measuring mediumLiquid or gas compatible with 316LDiaphragm material316LShell material304Protection levelIP66  Model & Structure (unit: mm)ModelFeatureOutline DrawingCYB18241. Waterproof socket2. Threads can be customized3. Pressure port type and material can be customized CYB18101. DIN43650 socket2. Threads can be customized3. Pressure port type and material can be customized CYB18201. Waterproof socket2. Pressure port type and material can be customized CYB18221. 0~1kPa~…100kPa2. For micro differential pressure.3. Overload protect, 500times CYB18301. 0~10kPa~…600kPa2. Aviation socket3. Can be connected with hose CYB18401. Direct cable, IP682. Pressure port type and material can be customized CYB18501. Ex d IIC T5 Gb2. LED / LCD display3. Pressure port type and material can be customized   Connection  Notes1. Please pay attention to the compatibility between the tested medium and some materials of the product joint during model selection.2. When installing differential pressure transmitter, please install the balance valve according to overload and prevent the transmitter from being damaged due to unilateral overload.3, when ordering the transmitter with LCD or LED head, the power supply of the transmitter should be no less than 15VDC.4. For installation occasions with lightning, please select products with lightning protection and install lightning protection pin on site to ensure reliable grounding of products and power supply and reduce the probability of damage to transmitter caused by lightning.5. When selecting digital display products, the working environment temperature range is from -30 to 70 C.6. The measuring range of the transmitter is 0kPa to 70kPa~3.5MPa. When the transmitter is selected, we should carefully check the specific parameters of differential pressure and pipe pressure, and select a reasonable corresponding range.7. The product is installed vertically on the field pressure interface, and the display level is directly aligned with the observer.8. If the ordered products need measurement verification certificate or other special requirements, please consult with our company and indicate in the order.     /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
