H21 Thermal Protector H21 Bimetallic Thermal Switch Temperature Sensor Thermostat

H20,H21 series thermostat's Principle and structureH20,H21serial universal and enhanced protectors with large metal casing are composed of the thermal conductive metal casing, bimetallic parts welded with silver alloy contact point, conductive bracket, insulation fixation stand, fixed contact strip and heat resistance cable. In case of abnormal operation, along with the increase of the environment temperature to the set value, the bimetallic parts perform quick action, open the contact point, and disconnect the circuit. When the device is cooled to the temperature for safe operation, the contact point will automatically closes and recover normal operation.H20,H21series thermal protector's SpecificationElectrical RatingDC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V max 16AOpen temperature(30~150)±5°C; 5°C a stepReset temperature2/3 of the action temperature with tolerance of ±15°C. Reset temperature can also be provided according to customers' requirement.Life times10000 timesContact Closure resistance:≤50mΩInsulation resistance:≥100mΩElectric strength:AC1500V/1min free from phenomena of break down and flashover.UL File no E487478CQC certificate noCQC16002142880TUV certificate no B160592241002H20,H21series thermal protector's DimensionModelCaseLength(mm)width(mm)High(mm)Vol.&CurrentLead wireH20Plastic18.584DC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V max 10A#20 3135, end 5mmhalf tripping, length is 70mm, or according to customer's requireH21Metal18.57.33.8H21Metal2084AC250V 20A#16 3135BH-A1DMetal156.63.2DC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V#20 3135, #22 3266,#22 3135, end 5mmhalf tripping, length is 70mm, or according to customer's requireBH-B2DPlastic157.13.8BH-TB02B-B8DPlastic155.22.4DC-12V max 4A; DC-24V max 3A; AC-125V max 3A; AC-250V max 2A3266-AWG24#, 3135-AWG24# or nickel strip normally, length is 70 mm or according to customer's requireH20,H21series temperature protector's ApplicationH20,H21series is applicable to chargeable battery, ballast, massager, micro motor, transformer, electric tools, heat electric appliance and instrument etc.The product UL,CQC,TUV and RoHS certification approval./* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
