High Quality Residual Current Operated Circuit Breaker RCCB 3p+N 6ka

General IntroductionDZ47-63 series earth leakage breaker is suitable for the leakage protection of the line of AC 50/60Hz, rated voltage single phase 240V, rated current up to 63A. When there is human electricity shock or if the leakage current of the line exceeds the prescribed value, it will automatically cut off the power within 0.1s to protect human safety and prevent the accident due to the current leakage. It can protect against overload and short-circuit. It can be used to protect the line from being overloaded and short circuited as well as infre-quent changeover of the line in normal situation. It complies with standard of IEC/EN61009-1 and GB16917.1.Specification  Frame class63ARated working voltage240VRated frequency50/60HzRated working current6,10,16,20,25,32,40,50,63ARated residual operating current0.01,0.03ARated residual un-operating current0.005,0.015SensibilityAC TypeMaximum operating timeIn t≤0.4s , 5In t≤0.01Instant release typeB,C typeLimiting value of un-operating current6InRated limiting short-circuit current10000APole number4PDimensionImagesFeature  The handle being sealable or equipped with padlock bracket avoids dangerous operation changes (ON / OFF)Clear indication of the contact positionEnergy limiting class: 3The emission of ionized gases is limited to the severest restrictions: 45 mm grid distanceSuitable for household or similar applications in accordance with:IEC 61009-1, tripping characteristics B, C and D.  Why Choose Us1.Experienced: our team has 13 years of experience2.Factory: Mature technics, strict attitude and perfect quality system3.Before leaving the factory sampling of products for lightning test, strict quality control4.Quality Assurance: Don't let the quality problems do damage to our brand5.Strict quality control, full-inspection. Professionally dedicated to SPD production  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
