220vac 48vdc 6000W Pure Sine Wave Inverter Charger UPS PURE SINE WAVE INVERTER 1. Max 70A charge current 2. Compatible with generator 3. For Solar, Home, Airconditioner, Generator and so on POWERSTAR PURE SINE WAVE INVERTER WITH CHARGER This equipment is suitable to use in family, and under special environments, the equipment can connect to perceptual load such as air conditioner, laser printer. Stability of this equipment is good, the charging current is big and the charge rate is also very high. The output wave for this equipment sine wave. Features: LED Display Buzzer Alarm Over-Load Protection Over-Voltage Protection Low-Voltage Protection Over-Temperature Protection Short-circuit protection Pure sine wave inverter charger Product Series LW1000LW2000LW3000LW4000LW5000LW6000General SpecificationInput Wave formSine wave (Utility or Generator)Nominal voltage120VAC230VACLow voltage trip90v + 4%184v/154v + 4%Low voltage reconnect100v + 4%194v/164v + 4%High voltage trip140v + 4%253v + 4%High voltage reconnect135v + 4%243v + 4%Max input AC voltage150VAC270VACNominal input frequency50Hz or 60Hz (Auto detect)Low freq trip47Hz for 50Hz, 57Hz for 60HzHigh freq trip55Hz for 50Hz, 65Hz for 60HzOutput wave form(Bypass mode) same as inputOverload protectionCircuit breakerShort circuit protectionCircuit breakerTransfer switch rating30amp or 40ampEfficiency on line transfer time95%+Line transfer time10ms TypicalBypass without battery connectedyesMax bypass current30amp or 40ampBypass overload current35amp or 45amp: AlarmInverter Specification OutputOutput wave formPure sine waveOutput continuous power watts100020003000400050006000Output continuous power VA100020003000400050006000Power factor0.9-1.0Nominal output voltage rms120/230VACOutput voltage regulation10% rmsOutput frequency50Hz + 0.3Hz or 60Hz + 0.3HzNominal efficiency> 88%Surge ratings300060009000120001500018000Short circuit protectionYes, fault after 10 secondsInverter Specification InputNominal input voltage12V24V48VMinimum start voltage10V20V40VLow battery alarm10.5V21V42VLow battery trip10V20V40VHigh voltage alram16V32V64VPower saverBelow 25watts when enabledPower saverSame switched on/off on remoteCharge Mode SpecificationInput voltage range95-127VAC194-243VAC/ 164-243VAC(W)Output voltage rangeDependent on battery typeCharge current35A/70ABattery initial voltage for start up0-15.7v for 12v (*2 for 24v; *4 for 48v)Over charge protection shutdown15.7v for 12v (*2 for 24v; *4 for 48v)OthersRemote control/RS232/USBYes, OptionalSize: in mm1000/2000/3000 Model: 442*218*179 4000/5000/6000 Model: 598*218*179Net weightLW1000LW2000LW3000LW4000LW5000LW6000 18kgs20kgs22kgs35gs38kgs40kgs /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
