976nm 60W High Brightness Fiber Coupled Laser Diode LD60W 976nm Fiber Coupled Diode Laser offers 60W output through a 105μm fiber. It uses a high-power proprietary chip optimized for reliability at high peak power. This Series leverages a long history of fiber-coupled packages, incorporating a highly-reliable design in a scalable commercial product. This series is a unique solution for the fiber-coupled pump-laser market, offering powerful technical attributes in a cost-effective package. Application:Laser Engraving machineMaterial processingIndustry application SpecificationItem No.: FC976DL60Optical Center Wavelength976±10nmOutput Power60WSlope Efficiency4.5W/AFiber Fiber Core Diameter105umFiber Numerical Aperture0.22NAFiber Length1mFiber ConnectorBare End/SMA905Electrical Operating Current 11.5~12.5AThreshold Current 0.5~0.9AOperating Voltage 8.5~12VPower Conversion Efficiency45%Thermal Operating Temp.15~55ºCStorage Temp.-30-70ºCWavelength Temp. Coefficient~0.3nm/ºCDimension About usHangzhou Brandnew Technology Co., Ltd.Founded in 2011, BrandNew, the laser diode company, manufactures high-power diode lasers and systems in a wide range of output powers and wavelengths including fiber-coupled, stack bar lasers and plug and play lasers.Cooperated with Institute of semiconductors Chinese academy of sciences and Zhejiang University, Today, over 60 technicians and 2 scientists, 20 technicians are with PHD degree. Production space is 10000 Class Lab Clean Room with 2000 square meters. Turnover per year is more than 10M US dollars.BrandNew's strengths are in talent employees, quality engineering,Process control, product development and volume manufacturing.Core CompetencyDiode Packaging Beam ShapingReliability Testing Efficient Cooling FAQCan you provide technology supports?Yes, we have a professional technology supporting team for your timely services. What about the delivery?We can offer the door to door services by air, just depend on your actual request. Such as DHL, UPS, TNT, FEDEXWhat is the lead time?Normally 3-5 days. Customized products need 15 working days.Do you have any MOQ limit?Low MOQ, 1pc for sample checking is available What is your terms of payment?T/T or Western Union, for your choice.Do you offer guarantee for the products?Yes, all products have been tested before shipping out.Lifelong technique support. One year warranty. /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
