2000PF 15kv High Power Ceramic Capacitor

CCG5 Cylindrical- shaped High Power Ceramic Capacitor is with mature processing technology, stable and reliable performance and complete range of models. Features: This product have the advantages of high withstand voltage, low dissipation factor, large reactive power, high frequency, long service life time and easy-installation, etc. Application: It's mainly used in equipment of high-frequency welded pipe, high-frequency drying, high-frequency electric oven, plastic thermal bonding machine and radio communication equipment. Specifications: 1.Typical dissipation factor: ≤0.0008;  2.Volume resistivity: ≥10000MΩ;  3. Permissible variation of rated capacitance: K(+/-10%);  4.Temperature range: -40/+85;  5. Rated temperature: +85ºC;  6.Maximum relative humidity: 75%; 7. Test voltage: 2 times of rated voltage if the rated voltage≤15KV or 1.5 times of rated voltage if the rated voltage>15KV. Pictures:   200PF/15KV     60KVA   D=60      400PF/17KV     75KVA   D=80      500PF/15KV     75KVA   D=80      800PF/25KV     90KVA   D=150    1000PF/14KV   70KVA   D=120    1500PF/15KV   90KVA   D=140    3000PF/10KV   90KVA   D=160       /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
