Kemapower Cabinet Lithium Battery Module 48V Rechargeable LiFePO4 Lithium Battery

PRODUCT DESCRIPTIONKEY FEATURES1. LiFePo4 lithium Energy storage Powerwall battery 2.56KWH/5.12KWH/7.68KWH/10.24KWH2. 6000 Cycle life(80% DOD@25ºC), 10 times more than AGM battery3. Usable Energy Ratio upto 95%, 25-50% more than AGM battery4. Compact Size and light weight , over 50% less than AGM battery5. Wide Operation temperature -20-60ºC 6. LED and LCD display For Cell / Pack / BMS / SET7. Wide Compatibility, Cooperate With Most Inverters8. Embedded BMS , Full protection and Balance9. Max 18 Modular recommend 2-8 PCS Parallel to extend , OPTION10. Customizable  base on customer requirement TECHNICAL SPECIFICATIONS MODELFP48100-PWLFP48200-PWBattery Pack ModuleRated Voltage51.2V51.2VRated Capacity Ah100Ah±3%200Ah±3%Rated Energy5.12KWH10.24KWHCycle Life6000 times @ 80% DOC.25ºCDesign Life timeOver 10 yearsDOD> 95%IP GradeIP21, IndoorCommunicationRS485 / CAN communication interface to Inverter , RS4851/RS4852 For Parallel Communictaion . OptionParallel  ConnectionMax 18PCS,  recommend 2-8 PCS, Reserved Address portal ( DIP Switch/ ADDR  ) . OptionDC Output ConnectorM8 boltDisplayLEDStandby/charge/discharge/fault/ CapacityLCDCell/Pack Vdc/ Amp/ Ah/Temp , BMS Status and also Parallel and System setProtection FunctionOver charge /Over Discharge/Over Temperature/ Over Current /internal Short Circuit  protection and Balance Modular and Cell Charge and discharge ( Option ), by Embedded BMSBattery Pack Charge/Discharge           Recommended Charge Current80A80A( Base on Kemapower 3KW/24VDC 5KW/48VDC Inverter. Customizable by customer)Max. Continue Charge Current100A100A Recommended Charge Voltage56.4V56.4V Recommended Discharge  Current150A150A Max. Continue Discharge Current175Amp175Amp Recommended Over Discharge Voltage 44.8V44.8VBattery CellCell typePrismatic,LiFepo4Rated Capacity Ah100Ah100Ah / 200AhRated voltage V3.2V3.2VPack Connection16S1P8S2P or 8S1P BMS Parameter (Customizable)Charge method CC/CV, 3.65V cut off,0.05C cut offMax Pulse Charge Current120% * Max. continue Charge CurrentOver charge Protection voltage58.4V58.4VOver Charge Voltage Return55.2V55.2VMax Pulse Discharge Protection Current300% * Max. Continue Discharge CurrentOver Discharge Protection Voltage32V32VOver Discharge  Return Voltage40V40VOver current protection delay time20 ±5 msShort protection delay time200-600 us.Reset For BMSyes. Inclued the RST switch. Wakeup functionBattery StandardIEC62619, CE, UN38.3, MSDSProduct Size ( Around mm) Customizable525*460*170850*525*180Product Weight  ( Around Kg)52104Package Size (mm)645*550*500985*645*500Package weight (Kg)71131/* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
