Port Any port in China Lead Time : Quantity(Pieces)1 - 10001001 - 5000>5000Est. Time(day)715To be negotiated6mm black zinc alloy aluminum with ring led illuminated metal push button switch is rather popular in the market all over the work. Customization service in available.And We control every aspect for you!ItemsParameter Install Hole Diameter 16mm Type Flat head/ high head Illuminating effect Ring LED/Dot LED/Customized Symbol Without LED Swtich Function 1NO1NC/2NO2NC Operation Type Momentary/ Latching Solder pin type Connection terminal 1.8*0.4 Rating 3A/250VAC Dielectric Intensity 2000VAC Contact Resistance ≤50mΩ Insulation resistance ≥1000MΩ Electrical Life ≥50,000cycles Mechanical Life ≥500,000cycles Temperature -20ºC~+55ºC Protection Level IP67, IK10 Operation Force about 3~5N Operation Stroke about 2.8mm Panel thickness 1-15mm Nut torque 5-14Nm LED voltage 3-720VAC/DC LED rated current 20mA LED color red/blue/green/yellow/white/bi-color/tri-color /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
