11kv/15kv/24kv/33kv Automatic Circuit Breaker with Chk4 Hemg Control

  No.ParameterSpecification requestedSpecification offered1Amount1001002MarchIndicateHEMG(SEL)3ModelIndicateCHZ4(SEL-651R-2)4Country of originIndicateCHINA(USA CONTROL)5Year of manufactureNO less than 2018 (Take advantage of the 100% of the equipment life and have updated control and communication systems)20186 TypeAutomatic, three-phase reconnector with electronic control.AUTOMATIC ,THREE PHASE RECONNECTOR WITH ELECTRONIC CONTROL7Operating room temperature-10 °c to 50 º CRecloser:-40 °c to 85 º C8Operating frequency60 HZ60Hz9NOMINAL capacity630 A30A10Service Voltage23 kV23KV11Maximum design voltage≥ 27 kV27KV12Was≥150 kV a 3000 m.s.n.m150KV@3000MSNM13Symmetrical interrupt Current 12.5 kA RMS12.5KA RMS14UseWeatherWEATHER15Degree of protectionIP65 the SuperiorIP6516Arc Extinction MediumVacuumVACUUM17Insulation mediumSF6 or vacuumVACUUM18Number of operations open/close at full load10 0001000019ShotElectric and manual ELECTRIC AND MANUAL20Auto Reconnect1 to 4 shots, user configurable.1 TO 4 SHOTS ,USER CONFIGURABLE 21Current measurement3 Transformers for measuring phase currents and residual current.3 TRANSFORMER FOR MEASUING PHASE CURRENTS AND RESIDUAL CURRENT22Voltage measurement6 voltage sensors, to measure phase-ground voltage and phase-phase on both sides.6 VOLTAGE SENSORS TO MEASURE PHASE GROUND VOLTAGE AND PHASE-PHASES ON BOTH SIDE23Power measurementMeasuring capacity: -Active, reactive and total power, single phase and three phase.-Power Factor.MEASURING CAPACITY:-ACTIVE ,REACTIVE AND TOTAL POWERSINGLE PHASE AND THREE PHASE ,-POWER FACTOR24Measuring harmonicsAbility to measure current and voltage harmonics. 25 Measure 10 analog input channels harmonic for current and voltage harmonicsUser-Configurable for integration of 1, 5, 10, 15, 30, 60 or 120 minutes.Interval support 5,10,15,30,60min record26Phase sequenceOn both sides of the Reconnector. On both sides of reconnector27External display of contactsof contact position, included in the tank.Complied. 7 inputs for external contact.28Life-SPAN counterTotal number of operations closing/opening and wear Automatic contacts.Complied ,total number of operations closing /opening and wear automatic contacts29Fault counterNumber of operations for each of the protections:-Phase Overcurrent-Overcurrent of ground-Negative sequence protection-Earth-sensitive-Low/over voltage-Low/over frequencyComplied ,Number of operations for each of the protections:-Phase Overcurrent-Overcurrent of ground-Negative sequence protection-Earth-sensitive-Low/over voltage-Low/over frequency30Manufacturing and design standardsANSI/IEEE C37.60 o IEC 62271-111.IEC 60529.IEC 60255.IEEE 1613IEC 61850-3Standards for operation in severe electrical environments.Attach compliance certifications in English or Spanish.ANSI/IEEE C37.60 o IEC 62271-111.IEC 60529.IEC 60255.IEEE 1613IEC 61850-3Standards for operation in severe electrical environments.Attach compliance certifications in English 31CONTROLElectronic for recording events stamped over time, includes software.  The control Panel must include the following: -Visual display with dimensions not less than 10cm by 8cm.-Numerical type relay, with keyboard for manual configuration and opening/closing operation, configurable through software for protection and reconnection options, -Non-volatile memory-Power supply with a range of 105-250 VAnd and long life battery as backup. The battery must be easily interchangeable and available on the market.-Surge suppressor for control panel power protection.-Control Language: Possibility to select between Spanish and English.-Includes battery status indicator.Electronic for recording events stamped over time, includes software.  The control Panel must include the following: Relay LCD is 6*1.5cm, it can display 16*2 characters.-Numerical type relay, with keyboard for manual configuration and opening/closing operation, configurable through software for protection and reconnection options, -Non-volatile memory-Power supply with a range of 105-250 VAnd and long life battery as backup. The battery must be easily interchangeable and available on the market.-Surge suppressor for control panel power protection.-Control Language: Possibility to select between Spanish and English.-Includes battery status indicator32SOFTWAREHave all the updated library/utility, which requires the computer to manage and manage it locally and remotely. Language of the software with the possibility to select between English and Spanish.Complied.Have all the updated library/utility, which requires the computer to manage and manage it locally and remotely. Language of the software with the possibility to select between English and Spanish.33Protection groups4 Configurable protection groupsComplied. Max 8 groups can be used.34Protection group Selection-Automatic by change in flow direction.-User-selectable.Complied,-Automatic by change in flow direction.-User-selectable35Protection functions-overcurrent protection against phase-phase and ph
