Efficient Condensation Control Mechanical Hygrostat (MFR 012)

MFR 012 Mechanical Hygrostat Efficient condensation control Adjustable relative humidity range High switching capacity DIN rail mountable The MFR 012 electromechanical hygrostat is designed to control the relative humidity inside enclosures. When connected to an enclosure heater (dehumidifier), it will energize the heater at the humidity set point in order to raise the dew point. This helps prevent damage and mal- function of electronic components caused by condensation and corrosion. Technical data:   Switching difference4 %RH (± 3 % tolerance) - at 50 %RHPermissible air velocity50 ft/sec (15 m/s)Contact typeSPDT / change-over contactService life > 100,000 cyclesMin. Switching capacity 100 mA @ AC/DC 20 VMax. Switching capacity 5 A resistive @ AC 250 V DC 20 WMax. inrush current AC 5 AConnection3-pole terminal, clamping torque 0.5 Nm max.: solid wire - AWG 14 max. (2.5 mm²) stranded wire (w/ wire end ferrule) - AWG 16 max. (1.5 mm²)Housing plastic, UL 94V-0, light greyMounting clip for 35 mm DIN rail, EN 60715Mounting position verticalOperating temperature +32 to +140 °F (0 to +60 °C)Storage temperature -4 to +176 °F (-20 to +80 °C)Dimensions 2.64 x 1.97 x 1.5" (67 x 50 x 38 mm)Weight approx. 2 oz. (60 g)Protection typeIP20ApprovalsUL File No. E164102  Part No.Setting range01220.0-00 35 to 95 %RHOur Services 1. Prompt reply: Any inquiry or questions would be replied within 24 hours.2. Quality Product: Manufacture company, each of the products is tested and calibrated.3. Hospitality: Offer smiling service and your visiting is highly welcomed4. Fast delivery: delivery time is within 3-7 days usually, other occasion depends on the order qty.Trade Information Trade TermsFOB,CIF,CFR,EXW,DDPPayment termsT/T,L/C,Western union,Paypal,Escrow,MoneyGramPayment conditions30% deposit in advance,70% balance before shipping.Delivery time3-7working days after deposit,2-4 working days for inventoryPackingNeutral carton,Wooden case for large sizeShippingBy sea,by air and by express deliveryPayment conditions30% deposit in advance,70% balance before shipping.Delivery time3-7working days after deposit,2-4 working days for inventoryPackingNeutral carton,Wooden case for large sizeShippingBy sea,by air and by express delivery  Company Profile/* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
