Coaxial Cable Rg Series (RG11, RG6, RG59, RG213, RG214, RG58)

Basic Info.Model NO. Coaxial Cable VoltageLowSheath PVC PackageWooden DrumsDelivery10-15daysConductor Copper MOQ1000StandardIEC,BS,ASTMTrademarkHuatongTransport PackageWooden DrumsSpecificationcopper cableOriginChinaHS Code8544492100Product Description Coaxial Cable Rg Series (RG11, RG6, RG59, RG213, RG214, RG58)BC: Bare Copper   CCS: Copper Clad SteelTC: Tinned Copper   CCA: Copper Clad Aluminum 1.Specifications:1)  RG6 Coaxial Cable  75ohm Double shield(standard)1.02mm BC/CCS Conductor + 4.57mm PE Foam + Al Foil + CCA/BC/Alloy Braiding + 6.9mm PVC Jacket 2)  RG6 Coaxial Cable  75ohm Tri-shield1.02mm BC/CCS Conductor + 4.57mm PE Foam + Bonded Al Foil + CCA/BC/Alloy Braiding + Al Foil + 6.9mm PVC Jacket 3)  RG6 Coaxial Cable  75ohm  Quad shielded1.02mm BC Conductor + 4.57mm PE Foam +  Bonded-Al Foil +  CCA/BC/Alloy Braiding  +  A Foil +  CCA/BC/Alloy Braiding + 7.3mm PVC Jacket 4)  Customers'specifications are welcomed 2. Product Description:1)     Center conductor:BC,TC,CCA,CCS2)     Al-foil:Non-bonded Al-foil, bonded Al-foil,double bonded Al-foil,and double         non-bonded Al-foil are available3)     Braiding wire:Al,BC,,TC,CCA,CCS Available4)     Braiding wire diameter:0.10,0.11,0.12,0.13,0.14,0.15,0.16mm available5)     Braiding net:32,48,64,72,80,96,120,128,144 and more available6)     Braiding coverage:Between 30-97%7)     PVC jacket of flame retardant,UL Available 3.Electrical characteristics@ Frequency MHzdB/100 ft. (MAX.)dB/100 meters (MAX.)5 MHz0.58 dB2.65 dB55 MHz1.60 dB5.25 dB83 MHz1.95 dB6.40 dB187 MHz2.85 dB9.35 dB211 MHz3.05 dB10.00 dB250 MHz3.30 dB10.82 dB300 MHz3.55 dB11.64 dB350 MHz3.85 dB12.63 dB400 MHz4.15 dB13.61 dB450 MHz4.40 dB14.43 dB500 MHz4.66 dB15.29 dB550 MHz4.90 dB16.08 dB600 MHz5.10 dB16.73 dB750 MHz5.65 dB18.54 dB865 MHz6.10 dB20.01 dB1000 MHz6.55 dB21.49 dB 4. Application: Used as a distribution cable for indoor CATV,CCTV systems and as a connection cable for satellite systems where lower attenuation required. 5. Packing: 1)     Packing Lengths:100/roll,200m/roll,300m/roll.305m/roll2)     Inner Packing:Wooden reel,plastic reel,and paper reel3)     Outer Packing:Carton box,pull out box,pallet available4)     Other packing available according to clients'request
