Silicone Cover Copper Conductor High Temperature Wire Cable

Product DescriptionSilicone Cover Copper Conductor High Temperature Wire CableRated Voltage : 600VConductor Material : Tinned/Silver/ Nickel Plated CopperInsulation Material : FEP/ PFA/PTFE/ETFEWorking Temperature : -60 °C to +200 °CStandard : ASTM/IEC Colors : Black,red,orange,white,green,yellow,blue,brown,grey,violet or customizedApplication : Various electric machines,electric ceramics,heating parts,car lighting,ballast etcProduct Parameters: Conductor Insulator Resistance Cross Section Conductor Construction Diameter Insulator Thickness Over Diameter Max at 20ºC mm2 No.x mm mm mm mm Ω/km 0.014 7x0.05 0.15 0.15 0.45 1343 0.035 7x0.08 0.24 0.15 0.54 525   0.05 7x0.10 0.3 0.15 0.6 376.2 1x0.26 0.26 0.17 0.6 376.2 0.07 1x0.30 0.3 0.2 0.7 245 0.08 7x0.12 0.36 0.2 0.76 227 0.12 7x0.15 0.45 0.2 0.85 150 0.2 7x0.20 0.6 0.25 1.1 83.5 0.35 19x0.16 0.8 0.25 1.3 49.5 0.5 19x0.18 0.9 0.25 1.4 36 0.75 19x0.23 1.15 0.275 1.7 22.7 1 19x0.26 1.3 0.25 1.8 19 1.2 19x0.28 1.4 0.3 2 15.3 1.5 19x0.32 1.6 0.3 2.2 11.7 2 19x0.37 1.85 0.3 2.45 9.45 2.5 19x0.41 2.05 0.4 2.85 6.86 4 37x0.37 2.59 0.4 3.38 4.51 6 37x0.45 3.15 0.5 4.2 3.05 Quality Inspection  Customer ProjectCompany ProfileHenan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & InternationalTrade,Founded in 2005, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 66,000 Square Meters, With Advanced20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million KilometersWe Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABCCables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.CertificationsPackaging & ShippingCooperative Customers/* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
