UV Resistance Solar Power Cable Coaxial Cable PV Cable

UV Resistance Solar Power Cable Coaxial Cable PV CableSolar Power Cable Coaxial Cable PV Cable Description:A. Application:Double insulation,electron-beam cross linked cables for photovotaic power station. Construction:Tinned copper,according toVDE0295/IEC60228,Class5 B. Material Properties/Standards: 1.Fire-resistant performance:IEC60332-1. 2.Smoke emission:IEC61034;EN50268-2 3.Low fire load:DIN51900 4.Approvals:TUV2PfG 1169/08.2007 PV1-F. 5. Application Standards:UNE211 23;UNE20.460-5-52, UTE C 32-502 Solar Power Cable Coaxial Cable PV Cable Technical Data:1.Nominal Voltage:U0/U=600/1000V AC, 1000/1800V DC ; 2.Test Voltage:6500V,50Hz,5Min.   3.Temperature Rating:45oC upto+125oC, -40oF upto+257oF, Ambient temperature:25years(TUV) -40oC  upto+90oC, -40oF upto+194oF, Max.Short circuit temperature:280oC, +536oF. 5.Bending Radius:Fixed installation>4X  Occasionally moved>5X Solar Power Cable Coaxial Cable PV Cable Specification:Construction  Conductor Construction Insulation Thickness Sheath Thickness Outer ø  Resistance Max. Current Carring Capacity Approx Weight n×mm²n/mmmmmmmΩ/KmAKg/Km2×1.530/0.250.70.88.3±0.213.3307.22×2.550/0.250.70.89.2±0.27.98419.42×4.056/0.30.70.812.0±0.24.755514.22×6.084/0.300.80.913.5±0.23.3970202×10.0142/0.300.91.117.6±0.21.9598292×16.0228/0.301.11.119.8±0.21.2413243Conductor: Tinned Copper,according to VDE0295/IEC60228,Class5  Insulation: Electron-beam cross-linked Polyolefin Copolymer TUV 2PfG/1169  Sheath: Electron-beam cross-linked Polyolefin Copolymer TUV 2PfG/1169  Nominal Voltage : AC 600/1000V DC 1000/1800V Characteristic:  Heat-resistant flame retardant,UV/ozone/hydrolysis/climate resistance Sheath Color :Black or as per customer's requeit   Temperature Rating:45°c upto +125°c         -40°F upto +257°F Ambient temperature:25years(TUV)      -40°c upto +90°c        -40°F upto +194°F Max.Short circuit temperature:280°c,+536°F Bending Radius:Fixed installation>4X        Occasionally moved>5X Solar Cable Certificate:Solar Cable Workshop:Solar Cable Package:Related Products:Our Services:1. Factory: 200,000 square meters, available for OEM; 2. Lead time: 5-7 working days after payment received; 3. Authentication: TUV, OHSAS, CCC, CQC, ISO9001:2008; 4. Payment terms: T/T, L/C, O/A; 5. Guarantee: 20 years; 6. QC inspection: Strict inspection before delivery; After-sales Service:1. All our cables will be tested well in production and before delivery.2. Please contact us if any problem, we will respond within 12 hours./* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
