Tunnel Mist Shower with 2 Functions of Air Blowing & Water Spraying

Tunnel Mist Shower with 2 Functions of Air Blowing & Water Spraying.It is equipped with centrifugal fan and the primary and high efficiency air filters. The product has the features of elegant appearance, compact structure, easy maintenance and simple operation. Meanwhile, we can produce the people and cargo air shower room with the electronic interlocking and infrared sensing device according to customers' needs.Material: SS304External Dimension(mm): 1700(W)*1740(D)*2200(H)Internal Dimension (mm): 800(W)*1500(D)*1960(H)Door size(mm) 800W*1960H, SS304,double hollowtoughened glass window,Two doors are equipped with electronic interlock system,one door is open, the other door cannot be opened.Nozzle Number: 5(3-sides spraying,1 top,2 both sides),Nozzle Material: copperLamp: waterproof LED *1pcSpraying Time: adjustable(0-999S)Control Panel: LCD Display, SS304 panelSS High pressure pump,1pc,Flow rate: 0.3L/Min,Pressure: 60Kg Power 120W57L Liquid storage barrel(manual observation and refueling) or stainless steel purified water pipe connected with quick joint for water supplyOmron Infrared induction sensorPower Supply: 220V,50HzAutomatic sliding doorTechnical Parameters:  ModelAS-S1AS-S2AS-S3AS-S4Applicable Number of People12-44-55-6Air Shower Time0- 99s (Adjustable)Number of Nozzle12 (Two Sides)24 (Two Sides)36 (Two Sides)48 (Two Sides)Mouth Diameter of NozzleΦ 30 mmΦ 30 mmΦ30 mmΦ30 mmSpeed of Air Flow at the Nozzle>25m/s>25m/s>25m/s>25m/sDimension of High Efficiency Air Filter (mm)600×600×120600 ×600×120600×600×120600×600×120Dimension of Air Shower Area (mm)800×900×196 0800×1900×196 0800×2900×196 0800×3900×196 0Outside Dimension (mm)1400×1000×210 01400×2000×21001400×3000×21001400×4000×2100Power Supply         :380V,50HZ, we can made nonstandard voltage for different country.Maximum Power Consumption1.1KW2.2KW3.3KW4.4KWAs the filtration equipment through the action of high strength air flow, the single person air shower room is often used in conjunction with clean room. It can remove the impurity such as dust on the working staff before they go into the clean room. Each side of our product has six nozzles with a wide distribution range. With the mouth diameter of 30mm, the nozzle can spray out the air quickly. The air showering time can be adjusted in the range of 0 to 99s. Thus, the air shower effect can be assured to be the best level, which guarantees the cleanliness of the clean room completely./* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
