Benchtop Horizontal Measuring Profile Projector Hoc400

Benchtop Measuring Profile Projector HOC400UsageBenchtop Measuring Profile Projector HOC400 series are reliable and affordable non-contact optical measuring system of high precision and efficiency. This series Profile Projector are widely used at the field of mechanism, meter, electronic, rubber industry for quality control. Horizontal Benchtop Measurig Projector can inspect all kinds of surface and outline of complicated work-piece, such as cam, screw thread, gear, milling cutter and so on. This preicisio measuring device is an effective metrical and analytic system for education, research institute and lab. Powerful Metrology Counter provides fast geometric computations solution The protractor screen has an effective diameter of 400mm(16"), allowing large workpieces to be inspected. The screen rotation can be digitally displayed with a resolution of 1' or 0.01° Features & Advantages1.400mm diameter screen with digtial protractor 2. Magnification accuracy: 0.08% contour, 0.12% surface 3. Halogen Profile and fiber surface illumination 4. Powerful Geometric multifunction data processing system 5. Aviable Mini printer, footswitch and other accesssories 6. Helix angle stage adjustable: ± 15° 7. Heavy-duty, metal construction 8. Greater range and high accuracy Features of Metrology Counter DC-3000(1). Skew (2). MM/inch conversion (3). ABS/INC conversion (4). Zero setting (5). 1/2 calculation (6). 0° 90° 270° 360° Conversion (7). Linear compensation (8). RS232 output (9). Geometric measurement   Technical DataItem No.HOC400-2515Working table' s size(mm)450*200mmStage Travel X-axis250mmStage Travel Y-axis100mm(for focus)Stage Travel Z-axis150mmAccuracy≤ (2.5+L/150)µm, L = length of the work piece measured ( unit: mm)ScreenScreen Diameter: 300mmwith 4 film clipsScreen rotary range: 0° -360°Rotary angle resolution: 1' or 0.01°Digital ReadoutMetrolgoy Counter DC-3000 with RS232 outputIlluminationTransmission and reflection: 24V/150w-halogen lamp.PowerAC110-120v, 200-240v, single phase 50/60Hz Total power 400WCoolingFansG. W/N. W210KG/160KGDimension(L*W*H mm)1090*585*1010 (mm)   Optional DeliveryMeasuring SoftwareEdge DetectorCharts(3 kinds)HOC400-20X ObjectiveHOC400-50X ObjectiveHOC400-100X ObjectiveHolder with ClampV-Block with ClampSwivel Center SupportMini-PrinterRotary tableCalibration ScaleStandard DeliveryDigital Readout DC-3000HOC400-10X ObjectiveScreen ClampFoot-SwitchPower CableLight sourceWarrantyWe guarantee 18 months Warranty time Quality System1. Establish the quality management system based on ISO9001, improve quality inspection, and ensure that all the finished products are qualified.2. All our measuring machines are with CE certification3. All our measuring machines are assembled and adjusted with linear accuracy, so that the instrument accuracy is guaranteed by hardware assembly and adjustment to the greatest extent.4. Our professional technical service team is familiar with the principle, structure, assembly, and software debugging of the instrument, freeing customers from worries!5. We has provided professional and complete measurement solutions for many large and medium-sized enterprises at home and abroad, andhas won the trust of customers!After-sale Service1. Free professional operation training2. Warranty: 18 months instead of 12 months3. Regularly upgrade of software is available free4. Available lifetime technical support  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
