VW-1 600V Soft Clear PVC Tube Connector Hose

VW-1 600v soft clear pvc tube  connector hoseGRADE:SB-PVCWorking temperature:-30ºC~+105ºCSTRUCTUREPVC tubing is produced with superior and environmentally friendly polyvinyl colloidal particle, after drying, extruded to tubing when heated up and liquated, then packing in rolls after cooling. USAGEWith the excellent flexibility, mechanical and dielectric capability, flame resistance performance, PVC tubing is widely used in outside insulation protection of outgoing wires of electrical appliances, transformers, electrical motors or lighting equipment, and electronic components, wire harness and etc.SPECIFICATIONItemUnit         Test  MethodNumerical Value   SB-300SB-600Voltage ratingV 300600Temperature ratingºCUL224105Voltage resistanceBefore aging UL224  23ºC2500V/60sec After aging UL224  136ºC 168hr2500V/60secVolume resistivityΩcmUL224≥1010Tensile strengthBefore agingMpaUL224  23ºC≥10.4 After agingMpaUL224  136ºC 168hr≥7.3 Elongation Before aging%UL224  23ºC≥100% After aging%UL224  136ºC 168hr≥100%Flexibility UL224  136ºC 168hrNo crackingHeat shock UL224  180ºC 4hrNo crackingCold bend UL224 -30ºC 1hrNo crackingCopper stability UL224  136ºC 168hrNo corrosionFlame resistance UL224VW-1Special instruction:The PVC tubing supplied for the customers should be based upon the samples which confirmed by both sides, not restricted by the above performance indeDIMENSION(One)The British system series of AWG AWG No.  I.D.(mm) Wall Thickness (mm) Package size(m/r) SB-300SB-600240.55±0.10.25±0.050.40±0.05305220.65±0.10.25±0.050.40±0.05305200.85±0.10.25±0.050.40±0.05305190.9±0.10.30±0.050.40±0.05305  181.0±0.150.30±0.050.45±0.05305171.2±0.150.30±0.050.45±0.05305161.3±0.150.30±0.050.45±0.05305151.5±0.150.30±0.050.45±0.05305141.7±0.150.30±0.050.45±0.05305131.9±0.20.30±0.050.45±0.05305122.1±0.20.35±0.050.50±0.05305112.4±0.20.35±0.050.50±0.05305102.7±0.20.35±0.050.50±0.0530593.0±0.20.40±0.050.50±0.0530583.3±0.20.40±0.050.50±0.0530573.7±0.20.40±0.050.50±0.0530564.2±0.30.45±0.050.50±0.0530554.7±0.30.45±0.050.55±0.0530545.3±0.30.45±0.050.55±0.0530535.9±0.30.45±0.050.55±0.0530526.6±0.30.45±0.050.55±0.0515217.4±0.350.45±0.050.55±0.5515208.3±0.350.45±0.050.55±0.55152  (Two)  The British system series Size (inch) I.D.(mm)Wall thickness(mm) Packing size (m/r)SB-300 SB-6005/168.0±0.350.45±0.050.55±0.051523/89.5±0.350.50±0.050.55±0.051527/1611.1±0.350.55±0.100.65±0.101521/212.7±0.350.55±0.100.65±0.101529/1614.3±0.40.65±0.100.75±0.10765/816.0±0.40.65±0.100.75±0.10763/419.0±0.40.65±0.100.75±0.10767/822.0±0.50.75±0.150.85±0.1576125.0±0.50.75±0.150.85±0.1576027.0±0.80.75±0.150.85±0.1576  Dimension (Three) The British system series I.D.(mm) Wall thickness(mm) Packing size (m/r)SB-300 SB-6000.80±0.10.25±0.050.40±0.055001.0±0.10.30±0.050.40±0.055001.5±0.10.33±0.050.45±0.054002.0±0.20.33±0.050.50±0.054002.5±0.20.35±0.050.50±0.053003.0±0.20.40±0.050.50±0.053003.5±0.20.40±0.050.50±0.053004.0±0.20.45±0.050.55±0.053004.5±0.30.45±0.050.55±0.053005.0±0.30.45±0.050.55±0.053006.0±0.30.45±0.050.55±0.053007.0±0.30.45±0.050.55±0.051508.0±0.350.45±0.050.55±0.051509.0±0.350.50±0.050.60±0.0515010.0±0.350.55±0.100.65±0.1015011.0±0.400.55±0.100.65±0.1015012.0±0.400.55±0.100.65±0.1015013.0±0.400.55±0.100.65±0.1015014.0±0.400.55±0.100.65±0.1015015.0±0.400.60±0.100.70±0.105016.0±0.400.60±0.100.70±0.105017.0±0.400.60±0.100.70±0.105018.0±0.400.60±0.100.70±0.105019.0±0.400.65±0.100.75±0.105020.0±0.500.65±0.100.75±0.105021.0±0.500.65±0.100.75±0.105022.0±0.500.70±0.100.80±0.105023.0±0.500.70±0.100.80±0.105024.0±0.500.75±0.100.85±0.105025.0±0.500.75±0.100.85±0.105026.0±0.500.85±0.100.85±0.1050Remark: Other size and color can be produced upon request.COLOR:  Transparent, black, white, red, yellow, brown, grey, etc. Sunbow PVC pipe can achieve full-color certification, maybe only Sunbow in China Because the UL certification range of Sunbow PVC pipe is 0.5~25.4mm pipe diameter, the peers are only in the range of 0.8~12.0mm, and the full-color UL certification of Sunbow PVC pipes, most of the peers only have black and white certification. Therefore, a customer of a well-known American brand motor directly places a trial order of $3,000 without samples. What the peers cannot do, Sunbow has done it. In the current industry, more than tens of millions of PVC pipes are produced, and more and more small factories and traders maliciously compare prices and mess up the market, but manufacturers with excellent product quality will never lose customers because of their low prices. Bo is the best example. Sunbow PVC pipes, due to the excellent quality of the products, do not need to compare prices, and successfully won the well-known American brand customers who do not need proofing and testing. American customers request samples from many manufacturers or traders in China. More than 5 samples were sent to customers, but after rigorous testing by customers, they were all NG, and none of them could meet customer requirements. Either the product performance index was unqualified, or T
