Properties of Standard Transparent Quartz Glass Tube/Transparent Quartz Glass RodThe content of SiO2 is higher than 99.95% in the product, and it has superior physical and chemical function, for example, heat resistance, corrosion resistance, good thermal function, mechanical function and light transmittance. Its hydroxyl content can be lower than 2ppm. It has widely applied in manufacturing halogen lamp, mercury lamp, light tube of copy machine, electric light source products of stage lighting as well as producing chemical pipelines and heat-resistant utensils, etc.Physical PropertyDataDensity2.2g/cm3Hardness570KHN100Tensile strength4.8×107Pa(N/m2)Compression strength>1.1×109 PaCoefficient of thermal expansion(20ºC-300ºC)5.5×10-7cm/cmºCThermal conductivity(20ºC)1.4W/mºCSpecific heat(20ºC)660J/kgºCSoftening point 1730ºCAnnealing point1250ºCThermal PerformanceCoefficient of linear expansion of quartz glass is lower than that of all other materials.As quartz glass has extremely low expansion coefficient, it has very good thermal shock resistance.Quarts glass is a poor conductor of heat.Optical PerformanceOne important difference between quartz glass and common glass is its great transmittance within the whole spectrum.Electrical PerformanceMain electrical properties of quartz glass are high dielectric field intensity, low dielectric loss and low electrical conductivity. Therefore, it is widely used in manufacturing high-frequency high-pressure insulator, particularly applicable in high temperature and high mechanical stress occasions.Chemical PerformanceQuartz glass is a kind of material with very good chemical stability, and will not react with water, saline solution and most acid. Compared with common glass, quartz glass does not absorb moisture or efflorescence. Only hydrofluoric acid and corrode quartz glass. It has to be noted that quartz glass is very sensitive to all alkali and alkaline compounds. Even the very little content of such compound will result in quartz glass devitrification at high temperature. 2.Quartz Further Processing SeriesHot processing products: quartz tube backing sealing, flanging, blister connecting, blisters, curved pipe and various hetero types, etc.Cold processing products: grinding, polishing, drilling, and processing of quartz materials of various shapes. /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
