3000kg Goods Cargo Passenger Freight Elevator Lift

3000kg Goods Cargo Passenger Freight Elevator Lift   Product Description:The structural design of Asia FUJI car elevator  adapts to the characteristics of sudden increase and decrease of car load, and solves the problem of uneven stress of traditional goods elevator. There are two operation button boxes in the car. The driver can operate the elevator without going out of the elevator.The load of Asia FUJI Elevator is large, generally more than 3 tons. The car has a wide volume, convenient front and back connection, and convenient and fast cargo passage.Elevator optional partsParameterCapacity  (Kg)PersonSpeed(m/s)Entrance(mm)Clear car dimension (mm)Car outside dimension(mm)Clear hoistway dimension (mm)Pit depth(mm)Overhead Height(mm)Pit reaction load(KN)  Load-supporting beam  reaction  load(KN)Rated power(KW)Power supplycapacityLead-in wireQNO.VOPCWXCDSWXSDHWXHDPDOHR1R2R3R4KWKVAMM263081.07001200X13001252X14662000X190015004000685424104.35.24  1.6    16004200    6.88.26800101.08001300X14501352X16162100X200015004000766028125.46.56  1.6    16004200    8.610.36  1.75    17004300    9.611.56  2.0    18004400    1113.261000131.09001450X16001502X17662300X200015004000907232156.47.76  1.6    16004200    10.712.86  1.75    17004300    11.7146  2.0    18004400    13.416.110  2.5    20004500    1720.4101250161.010001800X15501852X17162600X2050150042001058036188.510.26  1.6    16004300    13.516.210  1.75    17004400    14.817.810  2.0    18004500    1720.410  2.5    20004600    2226.4101350181.011001900X16001952X17662700X2050150042001159040209.311.26  1.6    16004300    14.917.910  1.75    17004400    16.319.610  2.0    18004500    18.722.410  2.5    20004600    23.428.1101600211.012002000X17002052X18662900X21501500420013610548261113.26  1.6    16004300    17.52110  1.75    17004400    1922.810  2.0    18004600    2226.410  2.5    20004800    27.53310Machine details:   Placement machine; host production line; ABB Engineering, etc.advanced technology Start with a board, make a door panel cut step by step, and then put it in the ABB Engineering. After completing the following operation process, the ABB robot and the line on the other side (shearing machine cutting plate → punching machine punching → bending → welding) works the same wayIt is a safety protection device. When the elevator is powered off, the ARD will provide emergency power to the elevator control system, so that the elevator car can slowly run to the leveling position and open the door to release passengersThe latest permanent magnet gearless tractor was used to replace the traditional worm gear traction machine,which realizing the ultra small size,light weight of the traction machine, also eliminating the mechanical consumption between gears. It can save energy by more than 60% compared with the previous elevator technology, and meet the environmental protection requirements of minimum vibration, minimum machine room, no need for oil, maintenance-free with minimum noise.Adopt NICE3000 new integrated control system. Using high-performance vector control technology and digital direct parking technology, the operation curve that is most suitable for human function is calculated according to the actual floor spacingOptional: Cabin,Landing Door,Ceiling and Floor.Poduction Process:The intelligent production line adopts ABB6700 series products, and adopts 360 rotation type, from feeding to bending, to enter the roll line turnover work, and at the same time, enters the stiffener, head, gluing and arc welding process. This production process is composed of a single direction private service control motor platform and a double head spot welding machine; it has high stability and efficiency, can achieve the best manufacturing accuracyFor our elevator high-end intelligent control system production is the core technology area of the whole project.This production line is SMT full-automatic production line, including printing, chip reflow welding, plug-in, test packaging, the main board of control system, external call board, car roof, etc., which are all produced by our company, few elevator manufacturers in China have;  Certification:After decades of development, we have achieved many certifications to meet the safety standards of each country, such as SGS. ISSO. EAC ...etcCooperation Team/Participate in international exhibitions/Customer VisitingPacking and Shipping:01.Firstly use plastic film to wrap and cover the machine 02.Then pack small parts in plywood box 03.Marked with required label or shipping mark 04.Use steel wire rope to fix in the container,so as to avoid damage because of movingOur Project:For all our customers, most of them we can have a long term cooperation relationship. Such like for our domestic customers, most of them are introduced by our old customers. For example,in a foreign state, we already have a customer buy the elevators from us. The other customers also want to import the elevatos, so he can inquire about which brand elevators from whic
