Product description:QYB106 sputtering film pressure transmitter adopts ion beam sputtering film technology, all-stainless steel integrated structure, high-sensitivity pressure core, all welded and enclosed in a stainless steel shell, with high accuracy, large output signal, long working life, and long-term stability Good performance, low power consumption, no hysteresis, good repeatability, etc. Mainly used in high-end industrial sites and military equipment. Features: *pressure overloads of more than 5 times*Withstand frequent pressure shocks, vibrations*Thin film sensor*Whole welded structure *Corrosion-resistant stainless steel *Working temperature reach to 125ºC*Customized pressure ports*CE,Intrinsically safe Applications: *Pressure monitoring of water supply or sewage treatment *Pressure monitoring and control of fluid machinery such as pumps and compressors *Pressure process detection in the food and beverage industry *Industrial boilers. HVAC. Refrigeration systems *Pressure control of fluid systems such as hydraulic and pneumaticProduct parameters:ParameterValueMeasure Range0~ 2500barOverload Pressure2×RP(rated pressure)Broken Pressure4×RP(rated pressure)Accuracy±0.5%F.S ±0.25%F.SOperate Temperature-40ºC~+150ºC (-40-200 degree C could be customized)Compensated Temperature-20ºC~+120ºCMedia CompatibilityCorrosive medium compatible with Cr18Ni9TiWiresTwo-wireThree/Four wireOutput Signal4~20mA0.5-4.5V0~5V0~10VPower Supply12~30VDC12~30VDCLoad(U-10)/0.02(ohm)>20kohmInsulation>100M ohm@50VElectrical connectorDeutsch and M12Pressure PortM20*1.5,G1/4,G1/2,etc.Response Time10msPressure FormGauge G. Absolute A,Sealed S.EMCEMI:EN50081-1/-2 EMS: EN50082-2 Model Selection Item NO.Type QYB106Thin-film Sputtering Pressure Transmitter Pressure RangeMeasuring Range (0~X)MPaFill out X directly CodeOutput Signal B1(4~20)mAB3(0~10)VB4(0~5)V CodeThread Connection P1M20×1.5P3G1/4P4G1/2 CodeElectrical ConnectionC1M12C2DeutschQYB106(0~40)MPaB1P1C1 Dimension: FAQ:1. How long will you reply me? Normally in 1 hours, no more than 12 hours.2. How can I get the quotation? Please provide specification and application including sensing element, pressure range, thread connection, pressure type, medium, electronic connection, shell material etc. More details, more accurate quotation and earlier response.3. Can I get sample? Contact with our staff online directly and they would check stock for you.4. Can I visit your factory? You are warmly welcomed, our factory is located at Baoji city, Shaanxi province, China.5. Can we use our logo on the products? Yes, we provide OEM/ODM service.6. How long is your warranty period? Warranty period from the date of acceptance of 12 months.7. What is your terms of payment? We could accept T/T, L/C, Western union, PayPal, credit Assurance./* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
