Stainless Steel Bellows Expansion Joint Customized PTFE Expansion JointProducts DescriptionThe single unrestrained metal expansion joint comes with one bellows section and end connections.It can be equipped with all kinds of connectors, such as pipe weld ends or flanges. This expansion joint is mainly intended to absorb movements of axial expansion, both thermal and mechanical. In addition, to a lesser extent, it can absorb angular and lateral movements. It does not restrain pressure thrust so adequate anchors and guides must be provided and they can be used only in piping systems that incorporate correctly designed anchors and pipe alignment guides.Product ParametersDN (mm)bellowscompensation dosagestiffnessmax size of radial direction shape Bmmtotal length L (mm)product typeactive area A cm2corrugation number naxial direction X0mmlateral direction Yo (mm)angular direction θ± (°)axial direction N/mmlateral direction N/mmangular direction Nm/ (°)connection typeadapter pipe Jflange Fcorrugated compensator:design pressure Pd = 1.0Mpa(10Kgf/ cm2)fatigue life[ N ]=1000times design temperature t = 20ºC403845.51.24282121414145230240TB81.1581411356.5300310505647.51.543881790201572502608156.5819418973403506579491.544222109241862502608186.582112179360370801384112365827152821935427082286329320133643801001554122.336983226302832843008249.16349403153643801503004111.5310099029842892843008226.165041129423643802005354172.6314931059222238938040083410674613241115005202507794162.131850191164004433H04008338.36925239020050052030010754212.83153615211459495426450842116768190122957059435012694215.9316821965359357742645084212684124572965705944001619420222.6191728582862626426450 8418.65958357343157059445020034201.92.321483963211956784264508407.74.61074495459857059450024284201.7223805322916057294264508406.941190665480357059460034734364.3315611797715068305766008711767812247753816840  Technical DrawingApplicationPacking and ShippingCompany Profile We supply innovative expansion joint solutions to meet the world's pipe expansion needs. We've grown to serve customers in the electric power, oil and petrochemical, pulp and paper, industrial and heavy equipment suppliers and a variety of OEM markets. We manufacture metal bellows and fabric expansion joints from DN50 to 10000mm diameter with different temperature.The pressure ranges for these designs range from full vacuum to 120 MPa.FAQ1. Q. Can I get the samples?         A. Yes, the small-size sample is free, but buyers needs to pay for freight costs.2. Q. What is Minimum Order Quantity?        A.The MOQ is according to the type and size.3. Q.Can you manufacture based on my drawing or specification?        A.Yes, customized drawing or specification is available, just send us your requirements.4. Q.What price terms do you accept?        A.Ex factory price, FOB price. We'll also be pleased to make CNF/CFR/CIF price for you.5. Q.What standard can you make?        A. EJMA, ASME, MIL-E, BS, JIS, CODAP, etc.We need to know the following information to quote you correct products:1. Technical Drawing of the expansion joint you need?2. What size do you need?3. Material of the bellows, pipe ends, or flange?4. What diameter of the expansion joint do you need?5. Working pressure6. Movement7. Working temperature8. Length9. Connection: Welding pipe ends or flange (ANSI, DIN, JIS, BS, AS, GOST, etc..)/* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
