Auto Garage Mixing Room Cheap Spray Paint Booth

Model: YS-MR-B Inside dimention: 2230*3480*2500-5680*3480*2500mm L*W*H Any Size Requirements Can Be Met Environmental friendly A. Paint mixing room provides a controlled area to safely mix paints. B. Paint mixing room contained an automatic fire extinguishing system. C. Paint mixing rooms are available in a range of sizes and specifications; Nonstandard sizes can be manufactured to suit a specific area. Warranty The goods are guaranteed for 12 months from the date of receipt, but the filters and lamps are not guaranteed. It cannot be applied for damages caused by negligence of operations or mishandling of the machine. ModelYS-MR-B1YS-MR-B2YS-MR-B3YS-MR-B4Inside Dimension2230 × 3480× 2500 mm(L× W× H)3380 × 3480× 2500 mm(L× W× H)4530 × 3480× 2500 mm(L× W× H)5680 × 3480× 2500 mm(L× W× H)Outside Dimension2330 × 3580 × 2550 mm (L× W× H)3480 × 3580 × 2550 mm (L× W× H)4630 × 3580 × 2550 mm (L× W× H)5780 × 3580 × 2550 mm (L× W× H)Escape Door1 unit, 650× 2000 mm(W× H)Room BodyWall panels and roof panels are double skinned, tongue and groove structure, thickness: 50mm, made by 0.376mm color steel with polystyrene(EPS) inside, color: white.Lighting SystemCeiling lights 2 units× 4pcs=8pcs36W, with electronic ballasts.Ceiling lights 3 units× 4pcs=12pcs36W, with electronic ballasts.Ceiling lights 4 units× 4pcs=16pcs36W, with electronic ballasts.Ceiling lights 5 units× 4pcs=20pcs36W, with electronic ballasts.Ventilation SystemExhaust air from bottom of back wall panels, with exhaust fan  , air capacity: 2200m3/h. Generator is with galvanized steel molding frame and white coated steel cover.Exhaust air from bottom of back wall panels, with exhaust fan  , air capacity: 2800m3/h. Generator is with galvanized steel molding frame and white coated steel cover.  Exhaust air from bottom of back wall panels, with exhaust fan  , air capacity: 3800m3/h. Generator is with galvanized steel molding frame and white coated steel cover.Exhaust air from bottom of back wall panels, with exhaust fan  , air capacity: 5000m3/h. Generator is with galvanized steel molding frame and white coated steel cover.Filtering SystemPre-filter, exhaust fiberglass filter.Control SystemPower supply switch, electrical outlet, fan operation and lighting switch./* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
