Wholesale Bulk Price CE Premium Quality Garage Paint Booth From Infitech

CE APPROVED INFITECH BRAND HIGH QUALITY PAINTING ROOM/ PAINTING CHAMBER(IT SUPER L8)Product DesignProduct Description   DESIGN STANDARDBS EN 13355:2004+A1:2009 BS EN 60204:2006+A1:2009AIRFLOWFull downdraft for painting and bakingINTERNAL DIMENSIONS8000*4000*2800mm(L*W*H)EXTERNAL DIMENSIONS8100*5760*3810mm(L*W*H)BASEMENT HEIGHT350mmDRIVE-IN-RAMPS3 pieces; size:2000*1030*320mm, diamond structurePLENUM HEIGHT600mmWALL PANEL/TOP PANEL50mm dual-skin insulated panels filled with heat resistant rock woolENTRANCE DOORManual door, 4 wing entry door (2 + 2 structure), size:3400* 3150 mm (W*H)PERSONNEL DOOR2 sets, size:800×2000 mm  (W*H)CEILING LIGHTING10 sets of light fixtures, each 6*18W, 1,080W totalSIDEWALL LIGHTING8 sets of light fixtures, each 4*18W, 576W totalBRIGHTNESS>1500LuxINTAKE SYSTEMDirect-type turbine fan, 1*11KW, 35,000m3/h, 600paEXHAUST SYSTEMDirect-type turbine fan, 1*11KW, 35,000m3/h, 600paFILTRATION SYSTEMPre-filter, Ceiling filter, Floor filter, Exhaust filter DIRECT HEATING SYSTEMEclipse AH-SP120/080, 1*300KWCONTROL SYSTEMPainting, heating painting, leveling, baking, emergency stop switch, failure indication, over-temperature alarm indication, baking delay stop protectionRATED POWER25KWFeaturesCabin structure • Wall panel vertical insert • Plenum height:600mm • Basement height:350mmLighting system • Money saving energy efficient T-8 fixtures • IP55 protection grade • 45 degree angled ceiling lights + vertical sidewall lightsAirflow system • Non-spark fan, SIEMENS motor • Motor and fan are completely separatedDirect-fired heating system • Burner:Eclipse AH-SP120/080 • Maximum operating temperature:80°C • Almost 97% combustion efficiency, save more than 25% energyFiltration system • Inlet filter: Bag filter • Ceiling filter: High efficiency SP-600G • Floor filter: Fiberglass paint arrestor filter • Exhaust filter: Activated carbon filter mat, M typeControls• We adopt advanced technology to optimally save energy, reduce emission and adjust the velocity according to the latest European Regulations which enforced the use of water base paint and European directive EN13355 relating to painting and drying booths.Product detailsTrade ShowCompany InformationGuangzhou Infitech is professional manufacturer of spray booth. What we supply is not only limited to manufacturing, but the whole solution from initial design and layout, technical consultation, manufacturing through to installation and maintenance. We pride ourselves in delivering customized products that suit your individual needs, both in terms of size and performance.CE APPROVED INFITECH BRAND HIGH QUALITY PAINTING ROOM/ PAINTING CHAMBER (IT SUPER L8)   /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
